Yamaha MG20XU อนาล็อก มิกเซอร์

Fully Loaded Mixer for the Studio and Stage!

The Yamaha MG20XU analog mixer is well-suited for portable rigs or permanent installations, with its rich features and outstanding sound quality. The MG20XU’s quality op-amp ensures that your mix sounds transparent and articulate. The MG20XU’s crystal clear D-PRE preamps will squeeze every drop of tone from your mics, with natural-sounding bass and smooth highs. Featuring onboard digital effects, switchable phantom power, a pad switch, one-knob compressors, EQ, plenty of I/O, and LED metering, the MG20XU can take on just about any task you throw at it. Utilizing many state-of-the-art features from Yamaha’s high-end consoles, the MG20XU is ready to work for you!

Tech Specs

• Type:Analog
• Channels:20
• Computer Connectivity:USB (2 x 2)
• Faders:16 + 2 + 1
• Inputs – Mic Preamps:12 x TRS/XLR Combo, 4 x XLR
• Phantom Power:20
• Inputs – Line:4 x TRS, 4 x RCA
• Outputs – Main:2 x XLR, 2 x TRS
• Outputs – Direct:2 x TRS (Monitor)
• Outputs – Other:4 x TRS (Bus)
• USB:1 x Type B
• EQ Bands:3-Band, Sweepable Mid
• Effects:Yes
• Aux Sends:2 x Pre/Post, 2 x Post
• Send/Return I/O:4 x TRS (Sends)
• Busses/Groups:4 x Bus
• Headphones:1 x 1/4″
• Rackmountable:Yes
• Height:5.1″
• Width:17.5″
• Depth:19.7″
• Weight:15.7 lbs.
• Manufacturer Part Number:MG20XU
