Tascam Model 12 Analog Mixer

Classic Design with Modern Capabilities

Whether you use it for rehearsal, live shows, or studio production, the TASCAM Model 12 is a great-sounding, easy-to-use multitrack recording solution. The Model 12 boasts a classic analog mixer-style design that’s both intuitive and immediate. Achieve precise control with 60mm faders, while tweaking your tracks with familiar EQ and Aux controls. High-grade preamps ensure top-notch sound that’s easily captured on an internal SD card at 24-bit/48kHz resolution. You also get a generous complement of I/O. Beyond that, DAW integration is a piece of cake, thanks to the Model 12’s built-in 12-in/10-out audio interface. The Model 12 is lightweight yet rugged, and can be transported from studio to stage with confidence, thanks to TASCAM’s legendary reliability.

Flexible routing and onboard effects

If you’ve ever used a small-format analog console or a classic Portastudio, you’ll already be familiar with the Model 12. Take control of your mix with 60mm faders, then tweak your tracks to perfection with 3-band EQs. Shape your output with a 3-band master EQ. Achieve great sound right from the start, thanks to eight high-grade mic preamps with +48V phantom power. You also get a full complement of I/O for integrating your instruments and outboard gear. At Sweetwater, we appreciate the Model 12’s old-school approach — no menu diving necessary!

Easy standalone multitrack recording

Recording with the TASCAM Model 12 is a breeze. Capture up to 12 simultaneous tracks (channels 1–10 plus stereo master) directly to SD card at 24-bit/48kHz resolution, with overdubbing functions. You also get flexible routing and onboard effects. The Model 12 offers easy standalone multitrack recording at its best.

TASCAM Model 12 Features:

• Great-sounding, easy-to-use 12-track multitrack recording solution
• Boasts a classic analog mixer-style design that’s both intuitive and immediate
• 60mm faders provide precise control
• Familiar EQ and Aux controls for tweaking your tracks
• Generous complement of I/O including 8 high-grade mic preamps
• Internal recording to SD card at 24-bit/48kHz resolution
• Flexible routing and onboard effects
• Built-in 12-in/10-out audio interface for easy DAW integration
• DAW and transport control
• Lightweight yet rugged design

• 10 channel analog mixer with 12-track digital recorder
• Eight mono mic inputs on XLR connectors with switchable phantom power (48V)
• Ultra-HDDA microphone preamps on inputs 1–6
• Eight channels can be used with high-impedance instruments like electric guitars/basses
• 10 balanced line inputs (six mono, two stereo)
• Multi-purpose stereo channel for input from mobile devices via Bluetooth or stereo mini-jack connector (CH 9/10)
• Inserts on input channels 1 and 2
• Mix-minus function on smartphone mini-jack input
• Two Aux outputs (monitor, effects) and two stereo outputs with independent master faders (Main, Sub)
• Selectable PFL/AFL monitoring modes and solo in place (SIP)
• Dedicated click output with tap tempo feature
• MIDI input and output
• One-knob compressor for all input channels
• Three-band equalizer with sweepable mids for all input channels
• Switchable low-cut filter (100 Hz) on each channel
• Semi-parametric EQ with sweepable mid band for aux or main outputs
• Built-in Bluetooth receiver for wireless playback
• On-board effects processor
• Compact 60-mm faders
• 12-segment LED output level meters
• XLR balanced outputs for main stereo bus
• TRS balanced outputs for sub and aux outputs
• Two headphones outputs with separate level controls
• Tascam multi-track recording engine
• Uses SD cards as recording media (up to 128 GB)
• Up to 12 tracks (10 input channels + stereo mix) can be recorded without the need for a computer
• Recording/playback format: Linear PCM (WAV format, 44.1/48 kHz, 16/24 Bit)
• Overdubbing, punch in/out recording
• Multi-track playback for advanced live performance
• Illuminated Play/Record/Stop buttons for better legibility in poorly lit environments
