Tascam DR-10CH
ยี่ห้อ : Tascam
ราคา : 7,990 บาท
7990
รุ่น :  Tascam DR-10CH เครื่องอัดเสียง
การจัดส่ง : ซื้อครบ 500 บาท จัดส่งฟรีทั่วประเทศ / จัดส่งด่วนภายในวัน ทั่วกทม. และปริมณฑล
การชำระเงิน : จ่ายหน้าร้าน 11 สาขา / โอนเงิน / เก็บปลายทาง / บัตรเครดิต /ผ่อนชำระ 0% (บางรายการ) / Shopee / Lazada
ลูกค้าองค์กร/ใบเสนอราคา
E-mail: musicarmsproject@gmail.com
ลูกค้าองค์กร/ใบเสนอราคา
E-mail: musicarmsproject@gmail.com
Description
OVERVIEW
- Tascam DR-10CH (DR10CH) Micro Linear PCM Recorder with Wireless System for Shure Microphones. Tascam DR-10CH Micro Linear PCM recorder with wireless system for Shure microphones.
- TASCAM’s DR-10C-series recorders connect to your lavaliere microphone to create a compact recording system that fits on a belt pack.
- The DR-10CS & CH recorders have both inputs and outputs, so they can either be used stand-alone or with a wireless transmitter. When used with a transmitter, the DR-10C acts as a backup to protect against wireless dropouts during recording. For lectures or worship services, the DR-10C can record the entire program before it gets to the front of house system. And for events like weddings and reality TV production, the DR-10C is a compact recording system for body mics.
- The lightweight DR-10C runs for hours on a single AAA battery. It records to standard microSD media. Recording features include auto-gain and a low-cut filter for…
INCLUDED IN BOX
- 1 x DR-10CH Recorder
- 1 x USB Cable
- 1 x Mini XLR4 Cable
- 1 x Silicon Band
- 1 x Belt Clip
- 1 x Soft Case
- 1 x Owner’s Manual – including warranty
About The Tascam DR-10CH Recorder
- Tascam DR-10CH Micro Linear PCM recorder with wireless system for Shure microphones.
- TASCAM’s DR-10C-series recorders connect to your lavaliere microphone to create a compact recording system that fits on a belt pack.
- The DR-10CS & CH recorders have both inputs and outputs, so they can either be used stand-alone or with a wireless transmitter. When used with a transmitter, the DR-10C acts as a backup to protect against wireless dropouts during recording. For lectures or worship services, the DR-10C can record the entire program before it gets to the front of house system. And for events like weddings and reality TV production, the DR-10C is a compact recording system for body mics.
- The lightweight DR-10C runs for hours on a single AAA battery. It records to standard microSD media. Recording features include auto-gain and a low-cut filter for simple setup. Its dual recording feature records a safety track of your audio at a lower level, so in case of distortion you have a non-clipped backup. When multiple units are used, an infrared signal can synchronize settings between recorders.
- Whether using it as a backup or as a primary recording system, there’s nothing else like the TASCAM DR-10CS and CH.
Specification
Recording media | microSD card(64MB to 2GB), |
microSDHC card(4GB to 32GB) | |
Media discharging | Push-Push type (Guard cover mounted) |
Recording format | WAV(BWF) |
Sampling frequency | 48kHz |
Quantization bit rate | 24bit |
Number of channels | 1-channel (Mono) |
Analog audio Inputs | |
Connector | More info for Pin Assign, please click here |
DR-10CH | Compatible with SHURE |
Mini XLR 4pin, Male (TA4M adapter) | |
MIC input gain | LOW / MID / HIGH |
Input impedance | 32kohm or more |
PHONES | |
Connector | 3.5mm(1/8″) stereo mini jack (DUAL MONO) |
USB | |
Connector | Micro-B type 4pin |
Protocol | USB2.0 HIGH SPEED mass storage class |
Power | 1 AAA battery (Alkaline battery/ Ni-MH battery / Lithium battery), |
USB bus power | |
Power consumption | 0.45W |
Battery operation time | WAV,24 bit / 48kHz Rec, without headphones, limiter : OFF , Dual Rec : OFF , JEITA Rec |
Alkaline battery (EVOLTA) | Approx 10 hours |
Ni-MH battery (eneloop) | Approx 8 hours |
lithium battery (Energizer ULTIMATE LITHIUM) | Approx 15.5 hours |
Battery (RTC) | Lithium × 1(built in with soldering) |
Dimensions | |
DR-10CS / DR-10CH | 52(W) × 55.6(H) × 24.4(D) mm |
2.0(W) × 2.2(H) × 1.0(D) inch | |
Weight | |
DR-10CS / DR-10CH | 63g (including battery) / 51g (without battery) |
Operating temperature | 0˚C to 40˚C |
Accessories | |
DR-10CS / DR-10CH | USB cable,Connection cable, Carrying case, Clip, Belt, Owner’s Manual (including warranty) |
Audio performance | |
Frequency response | 20Hz to 22kHz +1/-2dB (IN to PHONES) |
Computer compatibility | |
Windows | |
OS | Windows 7, Windows 8, Windows 8.1 |
Macintosh | |
OS | OS X Mountain Lion(V10.8), OS X Mavericks(10.9) |
Downloads
