TASCAM DR-100MK3

Product Information

Tascam’s top-of-the-line Handheld Digital Recorder, the DR-100mkIII boasts a signal-to-noise ratio exceeding 100dB, delivering the best audio performance in the history of Tascam portable stereo recorders. Designed to meet the needs of the most demanding audio designers and engineers, this new model combines robust reliability, an updated user interface and studio quality sonic performance to deliver a truly breathtaking audio experience.

Used in a variety of combinations, depending upon the selected function, the DR-100mkIII features dual AKM AK4558 converters with VELVET SOUND architecture, providing both high sound quality and low power consumption, achieving a signal-to-noise ratio of 102dB

The DR-100mkIII uses two independent AK4558 ADC converters. By eliminating interference between left and right channels, signal-to-noise ratio is maximized and audio fidelity is improved. In addition, each of those AD converters can work in a Dual ADC mode. The two AD converters work in tandem then combine their results for a 109dB S/N ratio, beating the (already excellent) 102dB S/N ratio achieved when recording in standard mode.

Note: As the S/N ratio when recording exceeds the S/N ratio of the entire circuit, data recorded in dual mono ADC mode will be limited to a 102dB S/N ratio when played back on the DR-100mkIII. This does not affect the S/N ratio of the actual file, which is maintained at 109dB S/N. The XLR/TRS inputs, used to connect external mics, deliver the highest sound quality and lowest noise of any TASCAM Handheld Digital Recorder. HDDA (High Definition Discrete Architecture) mic preamps are also included to maintain a pristine audio signal path throughout

A newly designed microphone housing for the directional mics is based on exhaustive research of previous TASCAM handheld recorders and achieves the perfect marriage of protection and performance. Similarly, the omnidirectional stereo microphone setup features a sound pressure level tolerance of 125dB SPL – able to withstand virtually any audio environment – and includes an integrated shock mount structure to suppresses unwanted vibration and handling noise. The Tascam DR-100mkIII supports high definition recording at both 96kHz/24bit and 192kHz/24, ensuring that remote recordings achieve the same sonic fidelity as their studio-born counterparts

Features

• AKM AK4558 converters with VELVET SOUND architecture deliver a S/N ratio of 102dB
• Dual mono mode, using independent AK4558 converters for both the left and right channels, provides a S/N ratio of 109dB
• External microphones supported with XLR/TRS inputs and built-in low-noise HDDA mic preamps
• Onboard dual (directional/omnidirectional) stereo microphones with integrated shockmounts deliver flexible recording options while retaining professional quality audio performance
• Supports up to 192kHz/24bit recording
• Robust design for real-world use
• Dual battery structure allows the built-in high-capacity lithium-ion battery to be used along with 2 AA batteries
• AA batteries may be replaced during operation (when using the lithium-ion battery) delivering hours of uninterrupted recording
• TASCAM’s unique Dual Level recording function allows simultaneous recording of a backup file at a lower gain level
• Dual format recording function allows simultaneous recording of both WAV and MP3 files
• Locking XLR/TRS combo jacks made by Amphenol
• Tough aluminum body to deliver years of reliable use
• High-precision clock featuring a temperature-compensated crystal oscillator (TCXO)
• Streamlined operation based on user feedback
• The user interface has been designed to provide clear visual feedback, and includes both a large LCD screen and dedicated status LEDs
• Select hardware switches for quick and positive setting control
