Roland LX-9

Premium Grand Performance in an Upright Cabinet

The LX-9 is the flagship piano in the premium LX lineup. With commanding looks, unrivaled sound, and nuanced expression, the LX-9 embodies everything you’d expect from a high-end concert grand piano—with all the benefits of an advanced modern instrument. Enjoy a host of digital features to enhance your experience, like Bluetooth connectivity, wireless control with the Roland Piano App, and maintenance-free care.

Acclaimed Hungarian pianist Alex Szilasi takes the stage at the iconic House of Music in Budapest for a captivating performance on the Roland LX-9—which features the same advanced sound engine across the range. Renowned for his mastery of Chopin’s works, Alex’s playing will transport you with his virtuosity and expressive touch. Sit back, relax, and immerse yourself in the beauty of music.

Elegant Expression

Discover rich, full sound with complex overtones and harmonics delivered by Roland’s advanced Piano Reality Modeling technology. From pianissimo to fortissimo, breathe life into your music with a wide dynamic range and nuanced playability. Add depth to specific notes through half-pedaling with the continuous sustain pedal. And personalize the sound by changing the timbre of the piano.

A Symphony of Sounds

The versatile LX-9 provides an extensive spectrum of tonal nuances and expressive capabilities that intuitively adapt to your playing. Begin gently to evoke a dignified, soothing timbre, and when you crescendo, the tone dynamically brightens in response to your touch. As emotions and technique intertwine in your playing, the LX-9 faithfully mirrors your passion.

Responsive Touch

The LX-9 delivers an organic playing experience that naturally responds to your touch. From commanding fortissimo excerpts to half-touch and rapid trills, the sensitive keyboard translates unlimited tonal colors. Legato, staccato, and other articulations ring true with precision key release control. Haptic feedback and the escapement mechanism provide immediate acoustic interaction within expressive passages. Long hybrid keys allow for a consistent weighted feel regardless of the hand position on the keyboard, reducing the risk of strain during extended practice sessions or performances.

Lose Yourself in Music

A space’s ambience is a crucial part of an acoustic piano sound. From a vast concert hall to an intimate studio space, Piano Reality Ambience puts six environments at your fingertips. Eight speakers independently deliver the sound of different instrument elements, including string and cabinet resonances, subtle hammer noise, and more. When you want to play silently, plug in headphones for an immersive solo experience.

Piano Designer

Dive deeper into your piano’s sound and adjust the character of each note, including string tuning and temperament. Fine-tune the tone and resonance to your space for the optimal acoustic response. Then save your tuning adjustments as customized presets to summon if several pianists share the LX-9.

Make a Connection

Access deeper settings, play along with streamed music, find digital scores, and more when you pair with the Roland Piano App and other music apps via Bluetooth. Discover additional digital features like Twin Piano mode for same-range duets, an onboard recorder to evaluate progress, and a metronome to hone your timing skills.

Envision Your Perfect Piano

Need help visualizing an LX in your home? Use our Piano AR to see how different pianos would look in your space. Select a model and use your smartphone to scan a room. A fully 3D piano will appear. You can change the angle, color, and finish or move it around until it fits perfectly.

SOUND GENERATOR

Piano Sound

Piano Reality Modeling

Max. Polyphony

Piano: Limitless (solo playing using ‘Piano’ category tones)
Other: 256

Tones

Total 324 Tones
Grand: 4 Tones
Upright: 5 Tones
Classical: 5 Tones
E.Piano: 12 Tones
Organ: 12 Tones
Other: 286 Tones

AMBIENCE

Piano Reality Ambience

Type: Studio, Lounge, Concert Hall, Wooden Hall, Stone Hall, Cathedral
Depth: 11 steps

KEYBOARD

Keyboard

Hybrid Grand Keyboard (88 keys Hammer Action Keyboard):
with Escapement, Ebony/Ivory Feel, High Precision Sensing and Haptic Key Vibration

PEDAL

Pedal

Damper (Responsive Damper Action Pedal, capable of continuous detection, Damper Modeling)
Soft (capable of continuous detection, function assignable)
Sostenuto (function assignable, with muffler pedal function)

SOUND SYSTEM

Sound System

Piano Reality Projection

Speakers

Cabinet Speakers: 25 cm (9-7/8 inches) x 2 (with Speaker Box)
Near-field Speakers: (12 cm (4-3/4 inches) x 8 cm (3-3/16 inches)) x 2 (with Speaker Box)
Center Near-field Speakers: 8 cm (3-3/16 inches) x 2
Spatial Speakers: 2.5 cm (1 inch) x 2 (Dome type)

Rated Power Output

33 W x 2
21 W x 2
13 W x 2
14 W x 2

HEADPHONES

Headphones

Piano Reality Headphones Ambience

CABINET

Cabinet

Music rest: with Music holders
Key cover: Fallboard type, with Keyboard Lid Switch

TUNING, VOICING

Touch Sensitivity

Key Touch: 100 steps, fixed touch
Hammer Response: Off, 10 steps

Master Tuning

415.3–466.2 Hz (adjustable in increments of 0.1 Hz)

Temperament

10 types (Equal, Just Major, Just Minor, Pythagorean, Kirnberger I, Kirnberger II, Kirnberger III, Meantone, Werckmeister, Arabic), selectable temperament key

Effects

Brilliance

Piano Designer

Lid
Key Off Noise
Hammer Noise
Duplex Scale
Full Scale String Resonance
Key Off Resonance
Cabinet Resonance
Soundboard Type
Damper Modeling
Soft Pedal
Single Note Tuning
Single Note Volume
Single Note Character

INTERNAL SONGS

Internal Songs

Total 394 songs
Listening: 27 songs
Ensemble: 30 songs
Entertainment: 20 songs
Do Re Mi Lesson: 30 songs
Lesson: 287 songs (Scale, Hanon, Beyer, Burgmuller, Czerny 100)

DATA PLAYBACK

Playable Software

Standard MIDI Files (Format 0, 1)
Audio File (WAV: 44.1 kHz, 16-bit linear format, MP3: 44.1 kHz, 64 kbps–320 kbps, requires USB flash drive)

RECORDER

Recordable Software

Standard MIDI Files (Format 0, 3 parts, Approx. 70,000 notes memory)
Audio File (WAV: 44.1 kHz, 16-bit linear format, requires USB flash drive)

BLUETOOTH

Bluetooth

Bluetooth Ver 5.0
Profile: A2DP (Audio), GATT (MIDI over Bluetooth Low Energy)
CODEC: SBC (Supports SCMS-T content protection)

COMPATIBLE ANDROID / IOS APPS (ROLAND)

Compatible Android / iOS Apps (Roland)

Roland Piano App

CONVENIENT FUNCTIONS

Convenient Functions

Metronome (adjustable Tempo/Beat/Downbeat/Pattern/Volume/Tone, with Rhythm Pattern: 80 patterns)
Dual
Split
Twin Piano (with Individual Mode)
Transpose (in semitones)
Speaker volume and Headphones volume automatically select function
Speaker Auto Mute
Volume limit function
Panel Lock
Panel Off
Auto Off

OTHER

Display

Graphic LCD 128 x 64 dots

Connectors

DC In jack
Input jacks: Stereo miniature phone type
Output (L/Mono, R) jacks: 1/4-inch phone type
USB Computer port: USB B (compatible with USB MIDI/Audio)
USB Memory port: USB A
Phones jack x 2: Stereo miniature phone type, Stereo 1/4-inch phone type

Power Supply

AC adaptor

Power Consumption

Power Consumption: 65 W (when using the included AC adaptor)
* Approximate power consumption when playing the piano at the center value of the volume: 25 W
* Power consumption when sound has not been played after power-on: 23 W
* Power consumption when in OFF mode (when the power automatically turns off): 0.2 W

Accessories

Owner’s Manual
“Roland Piano Masterpieces”
Leaflet “USING THE UNIT SAFELY”
AC adaptor
Power cord
Headphone hook

SIZE AND WEIGHT

Width (with lid closed)

1,395 mm
54-15/16 inches

Depth (with lid closed)

491 mm
19-3/8 inches

Height (with lid closed)

1,179 mm
46-7/16 inches

Width (with lid open)

1,395 mm
54-15/16 inches

Depth (with lid open)

502 mm
19-13/16 inches

Height (with lid open)

1,254 mm
49-3/8 inches

Weight

LX-9-PE､LX-9-PW: 111.0 kg/245 lbs
LX-9-CH: 109.5 kg/242 lbs
