Mogami Gold Speaker Cable

A truly a high definition speaker cable, Mogami Gold Speaker uses oxygen free-copper, wound in a unique coaxial configuration specifically for the power amp to speaker interface. This cable is self-shielding, extremely neutral and faithfully transfers every detail, at any sound or power level, while rejecting noise transfer into or out of the cable.

“I was stunned by how dramatically the coaxial 3082 speaker cable affected the sound of my NS-10Ms. I was using good wire before but the improvement the 3082 made was not subtle. The speakers sounded noticeably louder and the response more natural and extended. I had no idea speaker cable could be so significant. Thanks so much for a great solution and
a wonderful improvement on my monitoring!”

This standard speaker cable is designed to meet XLR audio connector cable clamp. Coaxial Design is used to provide as large a conductor size as possible, which results in the following features:

• Large conductor size of 2.0mm (close to #14AWG) despite small OD of 6.5mm (0.256″). (Same conductor size for both internal and external (shield) conductors.)
• Extremely low induction from outside and affection to outside.
• Suitable impedance as speaker cable.
• Better sound quality than quad nor regular parallel configuration. Now, specify MOGAMI #3082 as world standard of economy and popular professional speaker cable.

SPECIFICATIONS

Configuration
Part No.		W3082
Conductor	Details	80/0.18 OFC (80×33AWG)
	Size(mm²)	2.03mm² (Approx. #14AWG)
Insulation	Ov. Dia.(mm)	4.6Ø (0.181″)
	Material	PVC
	Colors	White
Served Shield	Details	80/0.18 OFC (80×33AWG)
	Size(mm²)	2.03mm² (Approx. #14AWG)
Jacket	Ov. Dia.(mm)	6.5±0.5Ø (0.256±0.0197″Ø)
	Material	Flexible PVC
	Color	Black
Roll Size		100m (328Ft) / 200m (656Ft) / 153m (500Ft)
Weight per 100m Roll		7.5kg

Back To Top
ELECTRICAL & MECHANICAL CHARACTERISTICS
