Lehle Dual Expression Pedal ฟุตสวิตซ์

Express yourself, twice! The LEHLE DUAL EXPRESSION is an active, wear-free expression pedal equipped with a precise magnetic sensor. Known from the LEHLE VOLUME pedals, this sensor uses the Hall effect, named after Edwin Hall, to measure the strength of magnetic fields.

In the LEHLE DUAL EXPRESSION the Hall sensor is accurately calibrated to the built-in magnet and the control range of the pedal – where the pedal moves only the magnet, whose distance is measured by the Hall sensor. Two digital potentiometers, working with analogue voltages, are used for the precise and reliable generation of the expression data.

Expression Pedal

• 2 Outputs
• Active, wear-free expression pedal equipped with a precise magnetic sensor
• 2 Digital potentiometers with analogue voltages for the precise and reliable generation of expression data
• Both outputs can be used with almost all common devices with expression inputs from 5k to 100k , including TS, TRS and/or RTS
• Polarity can be switched and stored via soft-push buttons
• The 10k output can be set as a latching- or momentary switch
• Via a USB jack you can send MIDI data to a computer for the control of MIDI-compatible software
• Resistance value of the potentiometer: 5-100 kOhm
• Button: Polarity
• LED: Polarity
• Connections: 2x 6.3 mm stereo jack
• Dimensions (W x D x H): 90 x 200 x 47 mm
• Weight: 766 g
• Made in Germany
