Ibanez AE275BT

The AE275BT is an AE series acoustic/electric baritone guitar model introduced by Ibanez for 2020. It is produced in China.

The AE275BT features a Venetian cutaway body shape constructed of a solid Sitka spruce top with standard X-M bracing on laminated okoume sides and back with a low gloss finish. The soundhole is round with an abalone and wooden rosette and a clear pickguard. It has a nyatoh Comfort Grip neck with a 20-fret katalox fingerboard with special wooden vine position markers and rounded edges. Components include a compensated bone saddle in a katalox bridge with Ibanez Advantage pins, a bone nut, and chrome die-cast tuning machines. Electronics consist of a T-bar undersaddle pickup and an Ibanez AP11 magnetic pickup mounted at the neck connected to an Ibanez Custom Electronics preamp, volume and tone controls and a ¼” endpin output.

• body shape
• AE body

• bracing
• X-M Bracing

• top
• Solid Sitka Spruce top

• back & sides
• Okoume back & Okoume sides

• neck
• Comfort Grip with Rounded Fretboard EdgeNyatoh neck

• fretboard
• Pau Ferro fretboard

• bridge
• Pau Ferro scalloped bridge

• inlay
• Specially designed Wooden Vine inlay

• soundhole rosette
• Abalone and Wooden

• tuning machine
• Chrome Die-cast tuners (18:1 gear ratio)

• nut material
• Bone

• number of frets
• 20

• saddle material
• Compensated Bone

• bridge pins
• Ebony

• strings
• D’Addario® XTAPB1670

• string gauge
• .016/.022/.029/.048/.060/.070

• string space
• 11mm

• factory tuning
• 1B,2F#,3D,4A,5E,6B

• pickup
• Ibanez AP11 Magnetic

• preamp
• Ibanez Custom Electronics w/ Volume and Tone Control

• output jack
• 1/4″ Endpin Jack
