Cranborne Audio Camden 500 Mic Preamp with Mojo

Cleanest, Crispest Recordings Possible

Cranborne Audio has designed Camden 500 from the ground-up. Their mission is to create the ultimate in front-end studio technology. Just by hearing the richness of the recordings, you will agree that their mission was a success. Ready to withstand the modern workflow and some of the tougher recording techniques, it is ready for anything you throw at it. The preamp tech is custom designed by Cranborne Audio to achieve a low-noise and low-distortion performance as well as frequency and phase linearity. This will give you the most crisp and freshest recordings possible, on every stage, from input to master. Across a wide range of dB levels, the Camden 500 will give you amazingly warm quality – whether you need to record a quiet input or serious power – you won’t be disappointed by the Camden 500’s clarity.

Don’t Lose your Mojo

Camden 500 comes with Mojo which is a great way for you to get vintage sound in your studio pipeline. It’s a new type of saturation method with incredible filters and discrete second/third order harmonic generators. The accurate, tactile knob means that your filtering can be dialed in to your own taste. From a slight vintage valve sound to an overdriven and clip-ridden signals. It’s there for when you need it, if you just want Camden 500’s beautiful clean tones then you can bypass Mojo entirely, but once you’ve heard it on your tracks, you’ll find little reason to avoid it.

Thump and Cream

When recording low end and bassy instruments, it can often be difficult to capture a crisp sound. Sometimes a lot of the clarity is lost because of low end roll off found in some other preamps. Thump is a wonderful tool that boosts the harmonics of 100Hz to 20Hz. It does all this without boosting the fundamental frequency which can often give your bassier tracks too much boom.

Cream gives you the vintage smoothness you need on your guitar, on your vocals or on anything you might want. The Cream setting drastically increases THD whilst smoothing-out the low-mids. The beauty of Cream is that it varies entirely on the harmonic signature of an incoming source, increasing the bright qualities of your instruments. Thump and Cream are amazing tools for crafting that specific sound and tone you want from your recordings. You won’t believe you managed without it.

Camden 500’s quality can revitalize your studio and give you a creative and technical edge.

Microphone Preamplifier and Signal Processor in 500 Series Module Format

• Linear, transparent microphone preamplifier
• 2 Discrete analogue saturation circuits for sound colouring
• THD+N: 0.0002 %.
• Frequency and phase linearity: Frequency response ±0.7 dB from 5 Hz to 200 kHz at max. gain and <2° phase shift between 50 Hz and 20 kHz
• Front-End topology with 68.5 dB gain across all 12 gain steps
• 3-Way input selector switch (Mic, line and instrument)
• Line recordings with +26.5 dBu input headroom
• DI input in BJT design and 1.5 MOhm input impedance
• Needs a 500 slot
• Form factor: 500 Series module

• Preamplifier ไมโครโฟนและตัวประมวลผลสัญญาณในรูปแบบโมดูล 500 Series
• พรีแอมพลิฟายเออร์ไมโครโฟนเชิงเส้นโปร่งใส
• 2 วงจรความอิ่มตัวของสีอะนาล็อกแบบแยกส่วนสำหรับการระบายสีเสียง
• THD+N: 0.0002 %
• ความถี่และความเป็นเชิงเส้นของเฟส: การตอบสนองความถี่ ±0.7 dB จาก 5 Hz ถึง 200 kHz ที่สูงสุด อัตราขยายและการเปลี่ยนเฟส <2° ระหว่าง 50 Hz ถึง 20 kHz
• โทโพโลยีส่วนหน้าพร้อมอัตราขยาย 68.5 dB จากขั้นตอนอัตราขยายทั้ง 12 ขั้นตอน
• สวิตช์เลือกอินพุต 3 ทาง (ไมค์ สาย และเครื่องดนตรี)
• การบันทึกบรรทัดด้วยเฮดรูมอินพุต +26.5 dBu
• อินพุต DI ในการออกแบบ BJT และอิมพีแดนซ์อินพุต 1.5 MOhm
• ต้องการสล็อต 500
• ฟอร์มแฟกเตอร์: โมดูล 500 Series
