AUDIX F2

f2

AFFORDABLE DYNAMIC INSTRUMENT MICROPHONE

The Fusion Series are high-performance microphones in a cost-effective package.

The f2 dynamic instrument microphone is best used for miking instruments requiring mid-bass and mid-high reproduction in live and studio applications. Its hypercardioid pick-up pattern helps to minimize feedback and isolate the instrument from ambient sound coming from the room or other instruments on stage.

Low impedance and balanced output on the f2 allow interference-free performance. Compact and durable, the f2 hypercardioid instrument microphone features a cast zinc alloy body, steel mesh grille and gold plated XLR connector.

Designed, assembled, and tested by Audix in the USA.

Capture Percussiveness with f2

Got Toms? You Need f2. The Audix f2 is a dynamic mic optimized for for rack toms and their floor-bound brethren. A member of the Audix Fusion Series, f2 excels at capturing the characteristic punchiness of percussive instruments such as congas, brass, sax, guitar, bass cabs – the spikier the better! f2’s hypercardioid pickup pattern gives you exceptional isolation and feedback control while its low mass diaphragm is delivering natural, accurate sound. f2’s tailored frequency response and 139dB SPL mojo allow you to mic almost anything and easily work with it in your mix. Sporting a US-made, precision-cast zinc alloy body and a durable black-coat finish, the f2 is at home in the studio or on the road. All excellent reasons why the Audix f2 should be in your mic locker.

Audix f2 Instrument Microphone Features at a Glance:

• Ideal instrument mic for stage and studio
• Perfect for rack toms, floor toms, congas, djembe, guitar and bass cabs, brass
• Hypercardioid pickup pattern gives you great isolation
• Rugged and roadworthy
• Built in the USA

• Transducer Type Dynamic
• Frequency Response 52 Hz – 15 kHz
• Polar Pattern Hypercardioid
• Output Impedance 580 ohms
• Sensitivity 2 mV / Pa @ 1k
• Capsule Technology LM Type A
• Off-Axis Rejection >20 dB
• Maximum SPL ≥139 dB
• Power Requirements None
• Connector 3-pin XLRm
• Polarity Positive pressure on diaphragm produces positive voltage on pin 2 relative to pin 3 of output XLR connector
• Materials / Finish Zinc Alloy / Black Finish
• Weight 247 g / 8 oz
• Length 104 mm / 4.09 in
