Arturia AudioFuse Rev2

Wide-ranging connectivity

Unique among interfaces its size, the Arturia AudioFuse Rev2 offers a stunning array of connectivity options. On top of its dual preamps, it includes two line inputs, two sets of stereo monitor outputs, two headphone outputs, and two RIAA phono preamps. Additionally, it has two inserts for integrating hardware effects and processors into a hybrid digital/analog setup, ADAT I/O to expand the unit’s inputs and outputs, Word Clock I/O, and MIDI IO, so you can externally control your favorite Arturia virtual instruments or internally control your outboard MIDI gear. Finally, it has a three-port USB hub for data connection and bus power.

AudioFuse Creative Suite included

When people think of Arturia, they think of the company’s 20 years of experience offering of world-class virtual instruments and effects. The AudioFuse Rev2 ships with the AudioFuse Creative Suite, a curated selection of some of Arturia’s most popular software that includes three channel strips modeled after legendary analog equipment, a hardware-emulated FET compressor, an iconic ladder filter, and Analog Lab Intro. It’s everything you need to dive in and start creating!

Arturia AudioFuse Rev2 Features:

• 14 input, 14 output channels
• 4 analog inputs: 2 mic/instrument/line, 2 phono/line
• 4 analog outputs; 2 analog inserts
• ADAT I/O, SPDIF I/O; Word Clock I/O
• MIDI I/O; 3-port USB hub
• 2 microphone preamps with DiscretePRO technology
• 2 RIAA phono preamps
• Latest generation 24-bit AD/DA converters at up to 192kHz sampling rate
• Option for analog soft-clipping
• Talkback feature with a dedicated built-in microphone
• A/B speaker switching direct monitoring
• Separate master and monitor mix channels
• USB interface with PC, Mac, iOS, Android, and Linux compatibility
• Includes built-in reverb
• Stylish, aluminum chassis

• Computer Connectivity:USB 2.0
• Form Factor:Desktop
• Simultaneous I/O:14 x 14
• Number of Preamps:2
• Phantom Power:Yes
• A/D Resolution:Up to 24-bit/192kHz
• Effects:AudioFuse Creative Suite Effects
• Analog Inputs:2 x XLR-1/4″ combo (mic/line/Hi-Z), 2 x 1/4″ TRS (line), 1 x Dual RCA Stereo
• Analog Outputs:2 x 1/4″ TRS (speaker A), 2 x 1/4″ TRS (speaker B)
• Digital Inputs:1 x Optical Toslink (ADAT), 1 x Coax (S/PDIF,Wordclock)
• Digital Outputs:1 x Optical Toslink (ADAT), 1 x Coax (S/PDIF,Wordclock)
• Inserts:2 x 1/4″ TRS
• Headphones:2 x 1/4″, 2 x 1/8″ (DC coupled)
• MIDI I/O:1 x 1/8″ TRS Type B (in), 1 x 1/8″ TRS Type B (out)
• USB:3 x Type A, 1 x Micro-B
• Clock I/O:In/Out (shared with S/PDIF)
• Other I/O:Built-in Talkback Mic
• Software:AudioFuse Control Center, AudioFuse Creative Suite
• Compatibility:iOS, Android, Mac, PC, Linux
• OS Requirements – Mac:OS X 10.8.5 or later
• OS Requirements – PC:Windows 7 SP1 or later
• Bus Powered:Yes
• Power Supply:AC Adapter / USB bus powered
• Height:2.6″
• Width:5″
• Depth:5″
• Weight:1.8 lbs
