เครื่องส่งสัญญาณ SHURE ADX1M=-P55 เครื่องส่งสัญญาณบอดี้แพ็คไร้สาย การป้องกันสัญญาณรบกวน

Wireless Bodypack Transmitter SHURE ADX1M = -P55 Tuning up to 184 MHz, anti-interference. Streamlined design and remote control from the SHURE brand.

PRODUCT DETAILS

The ADX1M is a wireless bodypack transmitter compatible with Axient Digital Wireless Systems.

ADX transmitters set the stage for exceptional performance, featuring wide tuning up to 184 MHz, interference protection, advanced rechargeability, streamlined design, and ShowLink remote control for real-time parameter adjustments right from the booth.

Note: When purchasing separate wireless components, please match their frequency bands to ensure proper system operation.

• Small and streamlined design for better concealment and wear (68mm × 60mm × 18mm)
• High-contrast OLED display
• Diversity ShowLink enabled for remote transmitter control and automatic interference avoidance
• Patent-pending internal adaptive antenna for optimized signal when ADX1M is worn against the body
• Ultem® PEI construction for heat resistance and durability
• Recessed LEMO connector
• Sealed buttons and LEMO connection for protection against sweat and moisture ingress*
• Two transmission modes: Standard for optimal coverage and new High Density for maximum system channel
  count and robust coverage
• Encryption-enabled, secure transmission
• Up to 7 hours of runtime with SB910M rechargeable batteries
• Detachable belt clip

SPECIFICATIONS
(SUBJECT TO CHANGE)

• Gain Offset Range
  –12 to 21 dB (in 1 dB steps)
• Battery Type
  Shure SB910M Rechargeable Li-Ion
• Battery Run Time @10 mW
  up to 7 hours
• Dimensions (H × W × D)
  2.4 × 2.7 × 0.7 in
  (60.4 × 68.0 × 18.0 mm)
• Weight
  1.9 oz (53 g)
  wihtout battery
• Housing
  Ultem®
  (PEI)

AUDIO INPUT

• Connector
  LEMO3 Connector
• Configuration
  Unbalanced
• Impedance
  8.2 MΩ
• Maximum Input Level
  1 kHz at 1% THD
  Pad Off: 8.5 dBV (7.5 Vpp)
  Pad Off: 20.5 dBV (30 Vpp)
• Preamplifier Equivalent Input Noise (EIN) System Gain Setting ≥20
  –120 dBV
  A-weighted, typical

RF OUTPUT

• Antenna Type
  Integrated Helical
• Impedance
  50 Ω
• Occupied Bandwidth
  <200 kHz
• Modulation Type
  Shure Axient Digital Propietary
• Power
  2 mW, 10 mW, 20 mW
  Varies by region. See Frequency Range and
  Output Power Table.
• Specific Absorption Rate (SAR)
  <0.24 W/kg

AVAILABLE MODELS

• ADX1M
  Axient Digital Showlink® -Enabled Micro Bodypack Transmitter, LEMO3 Connector
